Cabinet size: 18.3W x 5.1H x 8.6D cm (7.22W x 2.00H x 3.38D")
Weight: 1.0 kg (2.2 lb)
Input AC (to power supply): 100–240 VAC (±10%), ~50/60 Hz, 0.6 A
Output DC (from power supply): 24 VDC, 1.04 A maximum
Internal voltage: 24 VDC
Cycle rate Exceeds: 600 cycles per minute
Foot pedal: Voltage: 24 VDC; Current: 20 mA
Cycle initiate: Foot pedal, finger switch
Input air pressure: 7.0 bar (100 psi) maximum
Air output: 1.0–7.0 bar (1–100 psi) dependent on user setting
Ambient operating conditions:
+ Temperature: 5–45° C (41–113° F)
+ Humidity: 85% RH at 30° C non-condensing
+ Height above sea level: 2,000 meters maximum (6,562 feet)
Product classification: Installation category II; Pollution degree 2
Approvals: CE, UKCA, TÜV, RoHS, WEEE, China RoHS
