Metal frame and case painted with epoxy resins
5” TOUCH TFT digital screen colour display, for temperature setting and data input
Heating system two individually controlled resistances (resolution 0.1°C)
Operating temperature range 50 to 300°C
Thermal stability within ±0.2°C in the testing area
Test chamber Ø9.55 mm with made of steel (52/55 HRC)
Piston Ø9.474 mm, height of pressing part 6.35 mm, made of steel (52/55 HRC), overall weight 325 g, complete with weight support head and flag’s arm
Die internal Ø 2.095 mm, height 8 mm, made of steel (60/65 HRC)
Set of 4 adjustable feet for instrument levelling, assembled
Control mirror, assembled
Standard Tools
Sample loading funnel
Pressing tool for compressing the material in the test chamber
Die cleaning tool
Test chamber cleaning tools (3 different shapes)
Technical features
Power supply 230V, single phase, 50/60Hz, 0.5 kVA
Dimensions (WxDxH) mm 420x330x530
Weight approx. 25 kg
