Core: ARM Cortex M4
Technology: Si
Output Power: 15.2 dBm
Data RAM Size: 152 kB
Data RAM Type: SRAM
ADC Resolution: 12 bit
Data Bus Width: 32 bit
Interface Type: I2C, SPI, Serial
Mounting Style: SMD/SMT
Number of I/Os: 22 I/O
Number of Timers: 2
Processor Series: K32W041
NF - Noise Figure: 7 dB, 7.3 dB
Moisture Sensitive: Yes
Operating Frequency: 2.4 GHz
Program Memory Size: 640 kB
Program Memory Type: Flash
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.9 V
Number of ADC Channels: 8 Channel
Maximum Clock Frequency: 48 MHz
Operating Supply Voltage: 1.9 V to 3.6 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
