Depth: 1.7 mm
Shape: Round
Width: 2.95 mm
Length: 3.76 mm
Impedance: 400 Ohms
Port Type: Top
Dimensions: 3.76 mm x 2.95 mm x 1.7 mm
Sensitivity: - 42 dBFS
Mounting Style: PCB Mount
Frequency Range: 20 Hz to 20 kHz
Termination Style: SMD/SMT
Sound Pressure Level: 160 dBSPL
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.6 V
Directional Properties: Unidirectional
Operating Supply Current: 150 uA
Operating Supply Voltage: 2 V
SNR - Signal to Noise Ratio: 59 dB
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
