Protocol: BLE, Bluetooth 5.0
Data Rate: 125 kb/s, 500 kb/s, 1 Mb/s, 2 Mb/s
Frequency: 2.4 GHz
Dimensions: 12 mm x 12 mm x 2.31 mm
Output Power: 10 dBm
Interface Type: SPI, UART
Moisture Sensitive: Yes
Receiver Sensitivity: - 101 dBm
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.8 V
Antenna Connector Type: Internal
Supply Current Receiving: 5.3 mA
Supply Current Transmitting: 4.8 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
