Depth: 1.1 mm
Shape: Rectangular
Width: 3 mm
Length: 4 mm
Impedance: 300 Ohms
Port Type: Bottom
Tolerance: 3 dB
Dimensions: 4 mm x 3 mm x 1.1 mm
Output Type: Digital
Sensitivity: - 26 dB
Unit Weight: 24 mg
Mounting Style: SMD/SMT
Frequency Range: 100 Hz to 10 kHz
Termination Style: SMD/SMT
Sound Pressure Level: 120 dB
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.6 V
Directional Properties: Omnidirectional
Operating Supply Current: 540 uA
Operating Supply Voltage: 2 V
SNR - Signal to Noise Ratio: 64 dBA
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
