Light Source: White LED Light
Calibration Mode: Manual calibration
Scan Mode: Structured-light scan with automatic turntable
Scan Range: 150 mm x 96 mm/ 300 mm x 190 mm
Single Shot Accuracy: 0.035 mm/ 0.05 mm
Scan Speed: <70 s (8 scans/turn without texture); <3 s (single frame without texture)
Texture Color: RGB 24-bit color
Texture acquisition method: Fully automatic soft light shooting
Texture Map: 12 mega pixels, high fidelity color
Align Mode: markers alignment; feature alignment; manual alignment
Working Distance: 260 mm/ 480 mm
Point Distance: 0.0375 mm；0.075 mm；0.114 mm/ 0.075 mm；0.154 mm；0.23 mm
Data Format: OBJ, STL, ASC, PLY,3MF
Working Temperature: Indoor, room temperature
System: Win10; 64-bit
Recommended Computer Configuration: Graphics card: NVIDIA GTX/RTX series cards, higher or equal to GeForce GTX 1060; Video memory: ≥4 G; Processor: I7-8700; Memory: 32 GB
Size:
Host module: 332 mm x 110 mm x 142 mm (bare machine size)
Tripod components: 475 mm x 120 mm x 120 mm (bare machine size)
Turntable module: 320 mm x 320 mm x 68 mm (bare machine size)
Weight:
Host module: 2.7 KG (net weight)
Tripod assembly: 2.2 KG (net weight)
Turntable module: 2.1 KG (net weight)
