Core: ARM Cortex M0
Range: 200 m to 400 m
Width: 11 mm
Height: 2.2 mm
Length: 13.9 mm
Antenna: Chip
Features: Integrated Bluetooth Smart Ready Stack, Internal Temperature Sensor
Protocol: BLE, Bluetooth 4.1
Data Rate: 3 Mb/s
Frequency: 2.44 GHz
Dimensions: 13.9 mm x 11 mm x 2.2 mm
Memory Size: 128 kB
Sensitivity: - 96 dBm
Unit Weight: 1.850 g
Output Power: 12 dBm
Interface Type: GPIO, I2C, SPI, UART
Mounting Style: SMD/SMT
Frequency Range: 2.402 GHz to 2.48 GHz
Moisture Sensitive: Yes
Modulation Technique: BDR, EDR, LE
Receiver Sensitivity: - 96 dBm
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 2.2 V
Antenna Connector Type: Integrated
Operating Supply Voltage: 2.2 V to 3.6 V
Supply Current Transmitting: 92 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
