Fall Time: 9.5 ns
Rise Time: 10 ns
Technology: Si
Unit Weight: 76 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 17 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 55 W
Vgs - Gate-Source Voltage: - 25 V, + 25 V
Typical Turn-On Delay Time: 11 ns
Typical Turn-Off Delay Time: 41 ns
Id - Continuous Drain Current: 7 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 420 mOhms
Vds - Drain-Source Breakdown Voltage: 600 V
Vgs th - Gate-Source Threshold Voltage: 3 V
