Accuracy: 0.1 %
Gain V/V: 20 V/V
Shutdown: Shutdown
Topology: Half Bridge
Gain Error: 0.3 %
Technology: Si
Unit Weight: 24 mg
Qualification: AEC-Q101
3 dB Bandwidth: 750 kHz, 820 kHz
Amplifier Type: Precision Bidirectional
Mounting Style: SMD/SMT
SR - Slew Rate: 3.9 V/us, 7.5 V/us
Number of Channels: 1 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2.7 V
Ib - Input Bias Current: 350 uA
Operating Supply Current: 1.6 mA
Vcm - Common Mode Voltage: - 20 V to 70 V
Output Current per Channel: 10 mA, 20 mA, 25 mA, 36 mA
Vos - Input Offset Voltage: 500 uV
GBP - Gain Bandwidth Product: 750 kHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 100 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 120 dB
