Shutdown: No Shutdown
Gain Error: 0.04 % FSR
Resolution: 18 bit
Architecture: SAR
Sampling Rate: 8 MS/s
Interface Type: SPI
Mounting Style: SMD/SMT
Number of ADCs: 2 ADC
Reference Type: External, Internal
Development Kit: ADS9212EVM
Power Consumption: 220 mW
Reference Voltage: 4.096 V
Number of Channels: 2 Channel
Supply Voltage - Max: 5.25 V
Supply Voltage - Min: 1.15 V
Number of ADC Channels: 2 Channel
Pd - Power Dissipation: 232 mW
Maximum Clock Frequency: 96 MHz
INL - Integral Nonlinearity: 0.8 LSB
SNR - Signal to Noise Ratio: 92.3 dB
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
DNL - Differential Nonlinearity: 0.5 LSB
