Pulse Type: Unipolar pulses
Output Range: 10 A ~ 500 A
Adjust the Fineness: 0.01%
Amplitude Accuracy: ± 0.5%* range
Pulse Width: 1 ms ~ 100 ms
Pulse Width Adjustment Step: 0.1 ms
Pulse Width Accuracy: ± 0.1%
Current Rise/Fall Time: ≤10 μs
Amplitude of Current Overshoot: ≤20%
Maximum Load Voltage: 3.5 Vhp
-General Specifications:
Power Supply: Three-phase five-wire, AC (380±38) V, (50±2) Hz
Maximum Power Consumption: 6 kVA
Working Environment:
Temperature: 0°C ~ 40°C
Humidity: 20% R•H ~ 80%R•H, no condensing
Others: No electromagnetic field interference.
Storage Environment:
Temperature: -20°C ~ 70°C
Humidity: <95% R•H, no condensing
Communication Interface: RS232×1
