Physical
Processor: Intel® Broadwell-DE 8-Core @ 2.0GHz
Memory: 64GB DDR4
Storage: 128GB SSD
ASIC: Broadcom Jericho2 BCM88690
Broadcom OP2 BCM16K
BMC: AST2400
Chassis: 2RU, 436W x 762D x 87.6H mm (17.17" x 30" x 3.45")
Weight without FRU: 18.77kg (41.38lbs)
Redundancy: 1 + 1 Hot swappable power units
3 + 1 Hot swappable fan units
Environmental
Power Specs.: AC input: 200 to 240V, 12.5A
DC input: -40 to -72V, 60A
Typical power: 410Watts (no transceiver)
Operating Specs.: Operating temperature: 0°C to 45°C (32°F to 113°F)
Operating humidity: 5% to 85% (RH), non-condensing
Non-Operating Specs. : Storage temperature: -40°C to 70°C (-40°F to 158°F)
Storage humidity: 5% to 93% (RH), non-condensing
