Sensor: CMOS sensor with 1280 x 960 pixels
Aiming Element: 610nm
Illumination: Blue LED
Pitch Angle: ±60°
Roll Angle: 0 - 360°
Optical Resolution: 5.0 mil (Code 39), 6.6 mil (PDF417)
Depth of Field (DOF PCS=80%)
Symbology / X-DIM Typical Range* Near │ Far
5 mil Code 39 │ 2.4 in / 6.1 cm │ 9.5 in / 24.1 cm
5 mil Code 128 │ 2.8 in / 7.1 cm │ 9.0 in / 22.9 cm
6.67 mil PDF417 │ 2.4 in / 6.1 cm │ 8.0 in / 20.3 cm
10 mil Data Matrix │ 2.9 in / 7.4 cm │ 8.5 in / 21.6 cm
100% UPC │ 1.8 in / 4.6 cm │ 19.5 in / 49.5 cm
15 mil QR │ 1.2 in / 3.0 cm │ 11.5 in / 29.2 cm
20 mil QR Code │ 1.5 in / 3.8 cm │ 11.5 in / 29.2 cm
Communication: Wired
Supported Host Interface: USB / RS232
Dimensions: 87.8 L x 71.6 W x 177.7 H (mm)
Weight: 147g without cable
Trigger Switch Lifetime: 10 million times
Barcode: 1D, 2D
Operating Voltage: 4 VDC to 5.5 VDC
Current Consumption: Operating: 235mA / Standby: 60mA
Indicators: Beeper, LED
ESD Protection: Functional after 8K Contact and 15K Air
Mechanical Shock: 2.1M on concrete (scanner only)
Operating Temperature: -10°C to 50°C (14°F to 122°F)
Storage Temperature: -40°C to +70°C (-40°F to +158°F)
Protection Standard: IP42
Accessories (Optional):
■ Standard hands-free stand (Optional)
■ Auto-sensing hands-free stand (Optional)
Certifications: CE, FCC, BSMI, VCCI
