Image Sensor: CMOS Sensor, 1280 × 800 pixels
Aiming Element: 650 nm Laser Diode
Illumination: White LED
Skew Angle: ±60°
Roll Angle: 0° – 360°
Optical Resolution: 3 mil (1D), 6.6 mil (2D)
Depth of Field:
EAN-13 (13 mil): 70 mm – 500 mm
Code 39 (5 mil): 90 mm – 265 mm
PDF417 (6.7 mil): 70 mm – 225 mm
Data Matrix (10 mil): 65 mm – 215 mm
QR Code (15 mil): 40 mm – 295 mm
Communication: Wired
Supported Host Interfaces: USB / RS232
Dimensions: 87.8 (L) × 71.6 (W) × 177.7 (H) mm
Weight: 155 g (without cable)
Trigger Switch Life: 10 million actuations
Barcode Types: 1D, 2D, OCR and DPM
Operating Voltage: 4 VDC to 5.5 VDC
Current Consumption: Operating Mode: <314 mA / Standby Mode: <44 mA
Indicators: LED and Buzzer
ESD Protection: Functional after 8 kV Contact and 15 kV Air Discharge
Drop Resistance: 2.1 m on concrete (scanner only)
Operating Temperature: -10°C to 50°C (14°F to 122°F)
Storage Temperature: -40°C to +70°C (-40°F to +158°F)
Protection Rating: IP42
Accessories (Optional):
■ Standard Hands-Free Stand (PN# 5200-900009G)
■ USB Cable (PN# 1550-900127G)
■ RS232 Cable (PN# 1550-900060G)
Certifications: CE, FCC, BSMI, VCCI
