Width: 7.117 mm
Height: 3.23 mm
Length: 7.214 mm
Core Type: Molded
Shielding: Shielded
Tolerance: 20 %
Inductance: 2.2 uH
Application: High Current
Termination: Standard
Unit Weight: 1.255 g
Core Material: Composite
Qualification: AEC-Q200
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 8.1 A
Saturation Current: 10.8 A
Maximum DC Resistance: 18.3 mOhms
Self Resonant Frequency: 31.2 MHz
Maximum Operating Temperature: + 155 C
Minimum Operating Temperature: - 55 C
