Width: 8.18 mm
Height: 4 mm
Length: 8.18 mm
Core Type: Molded
Shielding: Shielded
Tolerance: 20 %
Inductance: 820 nH
Application: Automotive
Termination: Standard
Core Material: Composite
Qualification: AEC-Q200
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 20 A
Saturation Current: 16 A
Maximum DC Resistance: 4 mOhms
Self Resonant Frequency: 49 MHz
Maximum Operating Temperature: + 155 C
Minimum Operating Temperature: - 55 C
