Width: 17.15 mm
Height: 4 mm
Length: 17.15 mm
Core Type: Molded
Shielding: Shielded
Tolerance: 20 %
Inductance: 220 nH
Application: Commercial
Termination: Standard
Unit Weight: 7.780 g
Core Material: Composite
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 75 A
Saturation Current: 92 A
Maximum DC Resistance: 880 mOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
