Width: 6.5 mm
Height: 3.81 mm
Length: 8.7 mm
Output Type: NPN Phototransistor
Unit Weight: 400 mg
Configuration: 1 Channel
Mounting Style: Through Hole
Isolation Voltage: 5000 Vrms
Number of Channels: 1 Channel
If - Forward Current: 60 mA
Vf - Forward Voltage: 1.5 V
Vr - Reverse Voltage: 6 V
Current Transfer Ratio: 20 %
Pd - Power Dissipation: 150 mW
Maximum Collector Current: 50 mA
Current Transfer Ratio - Min: 20 %
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 55 C
Maximum Collector Emitter Voltage: 300 V
Maximum Collector Emitter Saturation Voltage: 400 mV
