Width: 4 mm
Height: 1.55 mm
Length: 5 mm
Output Type: NPN Phototransistor
Configuration: 1 Channel
Mounting Style: SMD/SMT
Isolation Voltage: 4000 Vrms
Number of Channels: 1 Channel
If - Forward Current: 60 mA
Vf - Forward Voltage: 1.5 V
Vr - Reverse Voltage: 6 V
Current Transfer Ratio: 20 %
Pd - Power Dissipation: 240 mW
Maximum Collector Current: 100 mA
Current Transfer Ratio - Min: 20 %
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 55 C
Maximum Collector Emitter Voltage: 30 V
Collector-Emitter Breakdown Voltage: 30 V
Maximum Collector Emitter Saturation Voltage: 400 mV
