Width: 6.3 mm
Height: 11.1 mm
Length: 11.9 mm
Slot Width: 3.1 mm
Wavelength: 950 nm
Output Type: Phototransistor
Unit Weight: 800 mg
Aperture Width: 1 mm
Sensing Method: Transmissive, Slotted
Number of Channels: 1 Channel
If - Forward Current: 60 mA
Vr - Reverse Voltage: 6 V
Pd - Power Dissipation: 250 mW
Maximum Collector Current: 4 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
Collector- Emitter Voltage VCEO Max: 70 V
