Width: 2.3 mm
Height: 2.6 mm
Length: 2.3 mm
LED Size: 2.3 mm x 2.3 mm x 2.6 mm
Lens Color: Colorless
Lens Shape: Dome
Unit Weight: 126.694 mg
Power Rating: 200 mW
Viewing Angle: 22 deg
Mounting Style: SMD/SMT
Lens Dimensions: 1.8 mm
Lens Transparency: Non-Diffused
Illumination Color: Red
Luminous Intensity: 5 cd
Moisture Sensitive: Yes
If - Forward Current: 50 mA
Vf - Forward Voltage: 2.2 V
Wavelength/Color Temperature: 630 nm
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 40 C
