Fall Time: 4.7 us
Rise Time: 3 us
Output Type: NPN Phototransistor
Unit Weight: 260 mg
Mounting Style: Through Hole
Isolation Voltage: 5000 Vrms
Number of Channels: 1 Channel
If - Forward Current: 60 mA
Vf - Forward Voltage: 1.6 V
Vr - Reverse Voltage: 6 V
Current Transfer Ratio: 40 %
Pd - Power Dissipation: 150 mW
Maximum Collector Current: 50 mA
Current Transfer Ratio - Max: 80 %
Current Transfer Ratio - Min: 40 %
Maximum Operating Temperature: + 110 C
Minimum Operating Temperature: - 55 C
Maximum Collector Emitter Voltage: 70 V
Maximum Collector Emitter Saturation Voltage: 300 mV
