Diameter of spindle（mm）: 110mm
Max.torque of spindle: 1225 N.m
Max.axial thrust of spindle (N): 12250N
Spindle taper: morse 6（7:24、50#）ISO50 7:24
Worktable travel (Z/X): 1400/1600mm
Distance from spindle center line to worktable surface: 0~1200mm
Max.travel of spindle: 600mm
Max. load of table: 3000kg
Speed number of spindle: 22 steps
Speed range of spindle: 8-1000r/min
Rapid traverse speed: 2500mm/min
Worktable working surface: 1600*1300mm
Rapid speed of rotary table: 1r/min
Boring accuracy: IT7
Roughness of boring hole: 3.2-1.6
Overall dimension(L*W*H): 5117*3359*3079mm
Machine weight: 17000kg
