Core: ARM Cortex M4F
Width: 8 mm
Height: 1.8 mm
Length: 11 mm
Protocol: BLE, Bluetooth 4.2
Data Rate: 1 Mb/s
Frequency: 2.44 GHz
Shielding: Unshielded
Dimensions: 11 mm x 8 mm x 1.8 mm
Modulation: DSSS
Memory Size: 64 kbit, 512 kbit
Sensitivity: - 96 dBm
Unit Weight: 220 mg
Output Power: 3 dBm
Interface Type: UART
Mounting Style: SMD/SMT
Frequency Range: 2.402 GHz to 2.48 GHz
Moisture Sensitive: Yes
Modulation Technique: DSSS
Receiver Sensitivity: - 96 dBm
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.8 V
Operating Supply Voltage: 1.8 V to 3.6 V
Supply Current Receiving: 5.4 mA
Supply Current Transmitting: 7.5 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
