Product Parameters:
Alternating current output
Output accuracy0.5 magnitude
Phase current output (effective value)0~40A
Three parallel phase current output (effective value)0~120A
Phase current value with long time under permission (effective value)10A
Phase current maximum power output400VA
Three parallel phase current maximum power output1000VA
Three parallel phase current maximum work time10s
Frequency range (base wave)20~1000Hz
Harmonic frequency number1~20 time
Direct current output
Output accuracy0.5 magnitude
Current output0~±10A/each phase, 0~±30A/every three parallel
Maximum output of load voltage20V
Alternating voltage output
Output accuracy0.5 magnitude
Phase voltage output (RMS)0~120V
Line voltage output (RMS)0~240V
Phase voltage/line voltage power output80VA/100VA
Frequency range (base wave)20~1000Hz
Harmonic frequency number1~20 times
Direct voltage output
Output accuracy0.5 magnitude
Phase voltage output amplitude0~+160V
Line voltage output amplitude0~+320V
Phase voltage/line voltage power output70VA/140VA
The switch quantity and time measurement
Switch parameters input (7ways)
Empty contact: 1~20mA, 24v
Power contact access: "0": 0~+6V; "1": +11V~+250V
Switch parameters output (2couples)
DC: 220V/0.2A
AC: 220V/0.5A
Time measurement
Measuring range: 0.1ms~9999s
Measuring accuracy: 0.1ms
Volume and weight
Appearance and size400mm×300mm×180mm
Weight of a single machine22kg
Working environment
Supply powerAC 220V±10%,50/60Hz
Environmental temperature-10℃~+50℃
