MATRIX WPS300S-150-5 Programmable DC Power Supply (0-150V, 0-5A, 300W)
Manufacturer: MATRIX Model: WPS300S-150-5 - Request a Quotation
- Request a Quotation
- Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best priceHanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Rated input voltage: AC220V/110V±10%
Rated output voltage: 0-150V
Rated output current: 0-5A
Rated output power: 300W
Load regulation rate: ≤0.02%+5mV / ≤0.02%+5mA
Line regulation rate: ≤0.02%+5mV / ≤0.02%+5mA
Setting resolution: 1mV / 0.1mA
Read back resolution: ≤0.1%+10mV / ≤0.2%+2mA
Setting accuracy (25℃±5°C): 1mV / 0.1mA
Read back accuracy (25℃±5°C): ≤0.1%+10mV / ≤0.2%+2mA
Ripple and noise (25℃±5℃): <10mVms / <3mAms
Temperature coefficient
+ Operating: 0 to 40°C ≤ 80R.H
+ Storage: -15 to 70°C≤ 80R.H
Machine size(W*H*D): 111*170*250 mm
Net weight: 2KG
