GAMRY Working Electrodes Electrodes (Length: 25.40 mm; Width: 7.26 mm)

Screen Printed Electrodes:

Sold in a pack of 20

Printed on a corundum ceramic base. Dimensions:

Length: 25.40 mm

Width: 7.26 mm

Thickness: 0.63 mm

2mm Au WE, Au CE, Ag/AgCl RE (printed)

Working electrode diameter is 2 mm,

Auxiliary electrode area is 4.00 +/- 0.05mm^2

Carbon Fiber Microelectrode Part No. 932-00011:

11 um disc

Glass/CTFE body

4 mm OD

Gold Microelectrode Part No. 932-00010:

10 um disc

Glass/CTFE body

4 mm OD

Platinum Microelectrode Part No. 932-00009:

10 um disc

Glass/CTFE body

4 mm OD

Platinum Working Electrode Part No. 932-00024 *:

3 mm disc

PEEK body

7 mm OD

Gold Working Electrode Part No. 932-00023 *:

3 mm disc

PEEK body

7 mm OD

Glassy Carbon Working Electrode Part No. 932-00022 *:

3 mm disc

PEEK body

7 mm OD
