JINKO JK5016 Multi-Channel Temperature Recorder (16 channels)

Display mode: 7 inch TFT LCD screen (with touch)

Display form: Data display, bar graph display, real-time curve display, alarm record

Channel No.: 16 channels

Module socket: 8

K type thermocouple: -100~1370℃, accuracy: ±0.5% + 0.6℃

J type thermocouple: -100~1200℃, accuracy: ±0.5% + 0.6℃

T type thermocouple: -100~400℃, accuracy: ±0.5% + 0.5℃

N type thermocouple: 0-1300℃, accuracy: ±0.5% + 0.6℃

R type thermocouple: 300~1768℃, accuracy: ±0.5% + 0.8℃

S type thermocouple: 300~1768℃, accuracy: ±0.5% + 0.9℃

PT100 Thermal resistance: -200~660℃, accuracy: +0.3℃ (Equipped with high precision PT100)

Resolution: 0.01℃

Recording interval: 1S-24h, can be set arbitrarily

Storage: Built-in 4G storage, U disk storage (U disk needs to be purchased separately)

Alarm function: Set upper upper limit, upper limit, low limit, low low limit

Temperature compensation: Support for each channel

Interface: RS232, Wi-Fi communication

Power supply: AC 65V-240V, DC 24V, Lithium battery power supply (optional)

Dimension: 288*288*200mm(L*W*D)

Weight: 3.4Kg

JK5000 adopts high-performance ARM microprocessor, 7-inch high-brightness true color LCD screen, full touch operation, Chinese and English operation interface and operation instructions, real-time display of measurement data and graphs. The test temperature resolution is improved to 0.01℃. Thermocouple model: K, J, E, T, N, S, B and R type. At the same time, in order to be applied to live applications, the instrument adopts a high-voltage isolation circuit, the main control unit and the interface unit can withstand 300VAC, and the allowable voltage between channels can withstand 300VDC.

There is a 4G large-capacity data buffer inside the instrument for real-time recording of data. The instrument supports 4 USB2.0 host interfaces. The instrument has a comparator function, outputs 10 channels of unqualified signals, and can directly drive power relays and signal relays. The instrument has a built-in LAN interface, RS-232C interface and USB232 interface can be effectively used for remote control and data acquisition and analysis.
