Microchip Technology BM71BLE01FC2-0B02AA USBアダプター Bluetooth BLEモジュール、シールドなし、アンテナなし、6x8mm、産業用温度

Width: 6 mm

Height: 1.6 mm

Length: 8 mm

Antenna: External

Protocol: BLE, Bluetooth 5.0

Frequency: 2.44 GHz

Dimensions: 6 mm x 8 mm x 1.6 mm

Memory Size: 24 kB, 32 kB, 256 kB

Sensitivity: - 90 dBm

Unit Weight: 5.358 g

Output Power: 0 dBm

Interface Type: I2C, SPI, UART

Mounting Style: SMD/SMT

Frequency Range: 2.402 GHz to 2.48 GHz

Moisture Sensitive: Yes

Receiver Sensitivity: - 90 dBm

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 1.9 V

Antenna Connector Type: RF Pad

Operating Supply Voltage: 1.9 V to 3.6 V

Supply Current Receiving: 3.2 mA

Supply Current Transmitting: 3.3 mA

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
