Weight: 1.25 lb
Stability: ± 0.3% Span/Year
Vibration: ASME B40.7
Compliance: CE, RoHS 2
Battery life: 1000 hr
Display Type: LCD
Accuracy Note: ± 0.08% Full Scale Span
Output Signal: Current, Voltage
Pressure Type: Differential
Pressure, Max: 30 psi
Pressure, Min: 0 psi
Accuracy Class: < 0.1%
Data Retention: 8 GB Micro SD card micro SD is included with configurations that have data logging option Can accept up to 32 GB Micro SD
User Interface: 4 membrane key switches
Menu Complexity: Advanced + Basic Menu Options.
Pressure Cycles: 1 million
Protective Boot: Adds another layer of durability to the pressure gauge
Calibration Note: 5-point NIST traceable calibration is a configurable option (it does not come standard)
Number of Digits: 4
Display Type Note: 4-digit LCD with backlight and 25 mm (1”) character height
Electrical Output: 4 to 20 mA, 0 to 5 Vdc, 0 to 10 Vdc
Materials, Wetted: 316 Stainless Steel
Pressure Accuracy: ± 0.08 %
Supply Power Type: DC
Enclosure Material: Thermoplastic
Display Segment Height: 1 in
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Storage Temperature, Max: 82 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 54 °C
Operating Temperature, Min: -17 °C
Enclosure rotation after securing fluid connection: ± 150°
Isolation between Case and Output Terminations, Min: 100MΩ @100 VDC
