Stewart Connector 940-SP-301010R-RMK4 モジュラー モジュラープラグ スタンダード 10P 10C シールドなし .032-.038 導体 RMK4キー付き

Color: Clear

Pitch: 1.02 mm

Gender: Plug (Male)

Shielding: Unshielded

USOC Codes: RJ50

Application: 10 Base-T

Unit Weight: 2 g

Tab Direction: User Selectable

Mounting Angle: Straight

Mounting Style: Cable Mount

Contact Plating: Gold

Number of Ports: 1 Port

Contact Material: Phosphor Bronze

Termination Style: IDC

Mounting Direction: Vertical

Number of Contacts: 10 Contact

Flammability Rating: UL94 V-0

Number of Positions: 10 Position

Performance Category: Cat 3

Number of Positions / Contacts per Port: 10P10C
