KEYSIGHT L7106C マルチポート電気機械同軸スイッチ (DC ~ 26.5 GHz, SP6T terminated)
生産者: KEYSIGHT Model: L7106C - 連絡先
Operating Frequency: DC to 26.5 GHz
Configuration: SP6T
Isolation (dB):
90 dB minimum, DC to 12 GHz
70 dB minimum, 12 to 15 GHz
65 dB minimum, 15 to 20 GHz
60 dB minimum, 20 to 26.5 GHz
Insertion loss (dB): 0.3 dB + 0.015 x frequency (GHz)
SWR:
1.2 maximum, DC to 4 GHz
1.35 maximum, 4 to 12.4 GHz
1.45 maximum, 12.4 to 18 GHz
1.7 maximum, 18 to 26.5 GHz
Connectors: SMA (f)
Please read the datasheet for ordering suitable products and options
