KIKUSUI PWR801H 安定化DC電源 (650V/ 3.7A)

Input voltage: 100 VAC ~ 240 VAC, 50 Hz ~ 60 Hz, single phase

Output power: 800 W

Output voltage:  650V

Output current: 3.7 A

Voltage:

Settable: max 682.5V

Setting accuracy:  ± (0.05 % of set + 0.05 % of rating)

Ripple noise: 300 mV p-p

Current:

Settable: max 3.885A

Setting accuracy:  ± (0.5 % of set + 0.1 % of rating)

Ripple noise: 12 mA

Display Functions:

+ Voltage: max 99.99, accuracy:  ± (0.2 % of reading + 5 digit)

+ Curent: max 999.9, accuracy: ± (0.5 % of reading + 8 digit)

+ Power: max 9999

Maximum internal resistance that can be set: 131.8Ω

Protection functions: Overvoltage, Overcurrent, Overheat, Power limit, shutdown

Other funtions: Sequence, Output-on/off delay, Soft start/stop, CONFIG shortcut, Synchronized operation

Control functions:  VPGM, IPGM, OUTPUT ON/OFF, SHUT DOWN, ALM CLR

Interface: RS232C, USB & LAN

Accessories: Chasis connection short bar, output terminal M4 screws (2 pcs.), output terminal cover, packing lisst, safety information, CD-ROM, Quick Reference, Power cord,...
