OWON HDS241 シングルチャネルハンドヘルドオシロスコープ (1CH; 40MHz)

Oscilloscope Specifications:

Bandwidth: 40MHz

Channel: 1

Sampling rate: 250MSa/s

Sampling method: Sampling, peak detection

Record length: 4K or 8K

Display: 3.5-inch LCD

Waveform refresh rate: 10,000wfms/s

Input coupling: DC, AC, GND

Probe attenuation: 1X, 10X, 100X, 1000X, 10000X

Maximum input voltage: 400V (DC+AC, PK-PK)

Sweep speed range (s/div):  5ns/div-1000s/div, Step by1-2-5

Sensitivity (Volt/div) range: 10mV/div-10V/div

Trigger Type: Edge

Automatic measurement: Period, Frequency, Mean, PK-PK, Max, Min, Amplitude, RMS

Cursor measurement: △V, △T

Interface: USB Type-C

Multimeter Specification:

Digital display: 24000 readings

Measurement type: Voltage, Current, Resistance, Capacitance, Continuity,Diode

Maximum input voltage: AC:750V DC 1000V

Maximum input current: AC:10A DC:10A

Diode test: 0-2V

Auto range: ✓

Continuity: <50Ω

TRMS: ✓

[Waveform Generator] Specification:

Output Frequency:

Sine: 10Hz-100kHz, Step by1-2-5

Square : 10Hz-100kHz, Step by1-2-5

Ramp: 10Hz-100kHz, Step by1-2-5

Pulse: 10Hz-10kHz, Step by1-2-5

Amplitude: 1Vpp or 2.5Vpp
