Vishay Dale IHB4BV181K Filter Inductor IHB-4 180 10% B40
生産者: Vishay Dale Model: IHB4BV181K - 連絡先
Height: 26.16 mm
Diameter: 40.64 mm
Core Type: Wirewound
Shielding: Unshielded
Tolerance: 10 %
Inductance: 180 uH
Application: High Current
Termination: Standard
Lead Spacing: 27.94 mm
Lead Diameter: 1.29 mm
Mounting Style: PCB Mount
Test Frequency: 1 kHz
Termination Style: Radial
Maximum DC Current: 7.1 A
Maximum DC Resistance: 45 mOhms
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 55 C
