Wurth Elektronik 7440710082 Power Inductors WE-TPC 8043 0.82uH 7.3A .007Ohm
生産者: Wurth Elektronik Model: 7440710082 - 連絡先
Width: 8 mm
Height: 4.3 mm
Length: 8 mm
Shielding: Shielded
Tolerance: 30 %
Inductance: 820 nH
Application: Power
Termination: Standard
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 7.3 A
Maximum DC Resistance: 9 mOhms
Self Resonant Frequency: 130 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
