Thông số kỹ thuật:
Thang đo độ cứng Vickers: HV0.3, HV0.5, HV1, HV2, HV2.5, HV3,HV5,HV10,HV20,HV30,HV50
hiển thị: giá trị độ cứng 5 chữ số, chiều dài đường chéo 4 chữ số (D1, D2), thời gian giữ, số lần thử, giá trị trung bình, v.v.
Lực thử (Kgf): 0.3, 0.5, 1, 2, 2.5, 3, 5, 10, 20, 30, 50kgf
Chế độ thử: HV/HK
Ống kính vật kính và công tắc đầu đo: công tắc tự động
Đo nhiều lần: có thể đo ống kính vật kính kép 10X, 20X
Kiểm soát tải: Tự động (tải/giữ/gỡ)
Thời gian duy trì lực thử: 1~99
Kênh quang học: Đèn kép kênh (thị kính và kênh camera CCD)
Hệ thống quang học:
Ống kính vật kính: 10×, 20× (option 40X) Độ phóng đại thị kính: 10× (option 15X)
Độ phóng đại tổng thể (μm): 100×, 200× Phạm vi đo (μm): 400
Độ phân giải (μm): 0.125
Ngôn ngữ: Tiếng Trung và tiếng Anh
Tiêu chuẩn thực hiện: ISO 6507, ASTM E92, JIS Z2244, GB/T 4340.2
Phạm vi đo độ cứng: (5-3000)HV
Chiều cao tối đa của mẫu (mm): 165
Chiều rộng tối đa của mẫu (mm): 130 (khoảng cách từ đường tâm của đầu đo đến tường)
Điện áp: AC220V/50HZ
Kích thước tổng thể (mm): 585×200×630
Trọng lượng (kg): 42
Main functions and features:
1. The optical system designed by senior optical engineers not only has clear images, but also can be used as a simple microscope with adjustable brightness and comfortable vision.
2. On the industrial display screen, the hardness value can be visually displayed, the hardness can be converted, the test method, the test force, the time of the charge and the number of measurements, and the test process can be intuitively understood.
3, Cast aluminum shell molding, the structure is stable and not deformed, high-grade automotive paint, anti-scratch ability, use for many years is still bright as new;
4. Our company has its own R&D, production and processing capabilities. Our machines provide parts replacement and maintenance upgrade services for life.
5, CHVS-50Z models can be achieved: observation - test - measurement of the position switch by the automatic turret
6.CHVS-50Z model can realize: the position switch of observation-test-measurement is completed by automatic turret;
7. Equipped with a large LCD screen; the large LCD screen display is convenient for observation, and the test conditions and test process are intuitive and clear;
8. Optional built-in printer; direct printing of test results and test data;
The main purpose and scope of application:
1. Iron and steel, non-ferrous metals, metal foils, hard alloys, metal sheets, microstructures
2. Carburizing, nitriding and decarburization layers, surface hardened layer, plating layer, coating
3, glass, wafers, ceramic materials, carbonization;
