Integrating sphere size: Φ40mm
Light source: Combined full-spectrum LED light source
Spectroscopic method: Planar grating
Sensor: Silicon photodiode arrays (dual row 32 groups)
Wavelength range: 400~700nm
Wavelength interval: 10nm
Semiband Bandwidth: 10nm
Measurement range: L:0~120
Measurement aperture: Single aperture: Φ8mm (Φ4mm optional)
Focusing method: Fixed Focus
Color space: CIE LAB,XYZ,Yxy,LCh
Observer angle: 10°
Illuminant: D65,A,F2(CWF)
Display accuracy: 0.01
Measurement time: Approx. 1.5s
Size: LxWxH=81x71x214mm
Weight: About 460g
Battery power: Lithium battery, 6000 times in 8 hours
Illuminant life span: 5 years, more than 3 million times measurements
Display: TFT true color 3.5inch, capacitive touch screen
Data port: USB, Bluetooth® 5.0
Data storage: 500 standard samples, 1,0000 samples , APP mass storage
Language: Simplified Chinese, English, Traditional Chinese
Operating temperature range: 0~40℃, 0~85%RH (no condensation), altitude< 2000m
Storage temperature range: -20~50℃, 0~85%RH (no condensation)
Standard Accessories: Power adapter, data cable, manual, SQCX quality management software (official website download), black and white calibration box, protective cover, wrist strap, single aperture: Ø8mm (optional Ø4mm) platform aperture, MOBCCS APP (official website download)
Optional Accessories: USB micro printer, powder test box, Bluetooth micro printer,holder base
