Measurement Geometry: 8 measurement angles (6 illumination sources, 2 receivers)
Measure Angle: 45° Receiver: 45as-15°,45as15°,45as25°,45as45°,45as75°,45as110°
15° Receiver: 15as-45°,15as-15°
Light Source: Full spectrum LED light source with blue enhancement
Lamp Life: 5 years, 3 million times measurements
Spectrophotometric Mode: Concave Grating
Sensor: 256 Image Element Double Array CMOS Image Sensor
Wavelength Range: 400nm-700nm
Wavelength Interval: 10nm
Measurement Range: 0~600%
Semiband Width: 10nm
Measuring Aperture: Φ12mm
Color Space: CIE LAB,XYZ,Yxy,LCh,βxy,DIN Lab99
Observer Angle: 2°/10°
Illuminant: D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4,F5,F6,F7(DLF),F8,F9,F10(TPL5),F11(TL84),F12(TL83/U30)
Measuring Time: Approx. 1 second for one angle; Approx. 8 seconds for all angles
Dimension: L*W*H=195*83*128mm
Weight: About 1Kg
Power: lithium-ion battery, 3.7V,3200mAh, Continuous test 6000 times within 8 hours of full charge
Display: 3.5-inch TFT color LCD, Capacitive Touch Screen
Interface: USB, Bluetooth 5.0
Data Storage: 1000 pcs Standards,4000 pcs Samples
Language: Simplified Chinese, Traditional Chinese, English
Operating Environment: 10℃~50℃, humidity does not exceed 85%, no condensation
Storage Environment: -20℃~50℃, humidity does not exceed 85%, no condensation
Standard accessories: Power Adapter, USB Cable, User Guide, PC Software(download from the official website), Calibration Board, black light trap,Protective cap, wristband
Optional Accessory: Micro-printer
