ACEY ACEY-BA3020-18 30V 20A Battery Charge and Discharge Aging Machine With Energy-Feedback Function

Number of Cabinet Channels: 18 channels

Channel Action Mode: Completely independent

Main Channel Operating Mode: Charging: constant current CC, constant current constant voltage charging CCCV; Discharge: constant current discharge CD, constant power CP; Standing and stopping.

Main Channel Test Stop Conditions: Time, voltage, current, capacity, etc.

Charging Voltage Range: 5V ~ 30V

Discharge Voltage Range: 5V ~ 30V

Voltage Accuracy: ±(0.1%RD+0.1%FS)

Voltage Resolution: 1mV

Maximum Output Current: Charge current 20A, discharge current 20A

Minimum Output Current: 100mA

Current Accuracy: ±(0.1%RD+0.1%FS)

Current Resolution: 1mA

Output Power: Single channel continuous operation maximum power 600W

Auxiliary Channel Parameter Cutoff Function: The main channel step can be set to stop or switch when the auxiliary channel signal reaches a certain condition.

Control Procedure: Support data protection due to power failure, manual stop and continued testing from data files.

Safety Protection Conditions: Lower voltage limit, upper voltage limit, lower current limit, upper current limit, voltage and current trend.

Auxiliary Channel Protection Conditions: Upper voltage limit, lower voltage limit, upper temperature limit, lower temperature limit.

Number of Cycles: Maximum 9999

Step Time Unit: Support h, min, s format

Data Upload Interval: Minimum 5S

Cycle List: Cycle number, charge/discharge capacity, charge/discharge efficiency, charge/discharge energy, charge/discharge average voltage, etc.

Process List: Process serial number, working mode, process time, capacity, energy, median voltage, termination voltage, termination current, etc.

Detail List: Record serial numbers, system time, cumulative time, voltage, current, energy, power, etc.

Data Export Method: The data can be exported into EXCEL and chart files, supporting various data analysis curves such as charge/discharge efficiency, charge/discharge curves, voltage, capacity, current-time characteristics, etc.

Advantages

1.Equipment accuracy (0.1%RD +0.1%FS), high stability;

2.Independent charging and discharging conditions can be set after free grouping for each channel;

3.Complete input and output, software and hardware protection, reverse connection protection, power-off connection protection and other functions;

4.Channel start without impact current, constant current to constant voltage seamless transition, without any current surge;

5.Network integrated management, a computer centralized control, support remote monitoring;

6.Modular design concept, box plug-in design, easy to maintain;

7.Clear and comprehensive data, real-time monitoring and uploading MES system;

8.The cabinet can be extended.
