ACEY ACEY-BMD-1 CR2032 CR2025 CR2016 Button Coin Cell Battery Manual Disassembly Machine

Air source: 0.6～0.8MPa argon, nitrogen gas cylinder, or compressed air (compressed air is not recommended in the glove box)

Exhaust design: specially designed exhaust port, which can be connected externally through KF40 and other devices

Air consumption: about 480ml of air consumption for a single seal

Sealing pressure: manual control valve control, pressure 1MPa, recommended pressure 0.7MPa, accuracy within ±0.5%

Sealing stroke: 30mm

Dimensions: 295mm × 200mm × 335mm

Weight: 30kg

1. Small size, easy to operate, can be placed in a glove box for operation.

2. Beautiful appearance, easy maintenance, small size, convenient operation, accurate molding, etc.

3. Built-in safety overflow oil valve, the pressure can be adjusted according to needs, and the upper pressure limit can be set to prevent damage caused by excessive pressure caused by misoperation, ensuring the safety of the machine.

4. Built-in pressure gauge can observe and accurately control the size of the sealing pressure.

6. Specially designed hydraulic structure, labor-saving operation.

7. Precision mold design ensures accurate and reliable sealing forming, solid steel structure design, stable and safe use.
