ACEY ACEY-S200C Automatic Single Side Rotary 18650 Lithium Battery Pack Spot Welding Machine

Y-axis Travel: 500mm (customizable)

X-axis Travel: 400mm (customizable)

Maximum Spot Welding Speed: 0.35s/point (about 2800 units of 18650 cells per hour)

Motor Drive Speed: 600mm/s

Rotation Angle: 180°

Maximum Battery Cell Loading Capacity: X direction: 26; Y direction: 26

Capable File Group Storage: 100 groups

Operating System: Embedded system human-machine interface

Transmission Mode: Taiwan precision screw with guide rail

Driving Mode: Stepper servo motor

Repeat Positioning Accuracy: ±0.02mm

Dimensions: L900mm × W900mm × H1650mm

Power: 2000W

Machine Weight: 150KG

Maximum Bearing Weight of Y-axis: 30KG

Input Power Supply: Single-phase AC220V/50Hz

Air Source: 0.4–0.6MPa

Features

1. Induce load voltage, control voltage by feedback, and realize high quality welding.

2. Preheat, Main Heat's power mode, preheating before welding, to ensure stable welding quality.

3. Keep the continuity of energy density, shorten the welding time, and reduce the deformation and color of base metal. (Welding time controlled in microseconds, continuous output mode)

4. Easy to change from low current to high current, suitable for precision welding.

5. The upper and lower limits of current can be set to simply judge whether the welding quality is good or not, which is suitable for welding automation platform.

6. Can be matched with the production line of lithium battery group.
