Adam Tech UC10-24S24 절연 DC-DC 컨버터, 절연 모듈, 단일 출력, 9V-36VDC 입력, 24VDC, 10W

Width: 14 mm (0.551 in)

Height: 9.8 mm (0.386 in)

Length: 24 mm (0.945 in)

Output Power: 10 W

Mounting Style: Through Hole

Isolation Voltage: 1.6 kV

Number of Outputs: 1 Output

Input Voltage - Max: 36 V

Input Voltage - Min: 9 V

Input Voltage, Nominal: 24 V

Output Current-Channel 1: 416 mA

Output Voltage-Channel 1: 24 V

Maximum Operating Temperature: + 77 C

Minimum Operating Temperature: - 40 C
