Gender: Jack (Socket)
Polarity: Standard
Impedance: 75 Ohms
Isolation: Isolated
RF Series: BNC
Body Style: Bulkhead
Body Finish: Nickel
Orientation: Right Angle
Unit Weight: 14.305 g
Body Material: Zinc Die Cast
Mating Cycles: 500
Mounting Style: Bulkhead - Rear Mount
Voltage Rating: 500 V
Contact Plating: Gold
Contact Material: Phosphor Bronze
Maximum Frequency: 1 GHz
Termination Style: Solder Pin
Coupling Mechanism: Bayonet
Contact Termination: Solder
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
