Analog Devices ADPA7005AEHZ-R7 전력 증폭기 31 dBm P1dB, 15 dB 이득

Gain: 15.5 dB

Technology: GaAs

Mounting Style: SMD/SMT

Input Return Loss: 18 dB

NF - Noise Figure: 11 dB

Number of Channels: 1 Channel

Operating Frequency: 18 GHz to 44 GHz

Pd - Power Dissipation: 12.33 W

Operating Supply Current: 1.4 A

Operating Supply Voltage: 5 V

P1dB - Compression Point: 29 dBm

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
