Life: 10000 Cycle
Actuator: Paddle
Illuminated: Non-Illuminated
Unit Weight: 21.397 g
Bushing Size: M12
Contact Form: SPDT
Mounting Type: Bushing
Terminal Seal: Sealed
Actuator Style: Paddle
Current Rating: 12 A
Mounting Style: Panel Mount
Actuator Length: 13.5 mm
Contact Plating: Silver
Switch Function: (ON) - OFF - (ON)
Contact Material: Nickel
Housing Material: Polyester
Actuator Material: Polyamide (PA)
Termination Style: Quick Connect
Voltage Rating AC: 250 VAC
Voltage Rating DC: 24 VDC
Flammability Rating: UL 94 V-0
Maximum Operating Temperature: + 55 C
Minimum Operating Temperature: - 20 C
