Width: 12.7 mm
Height: 8.5 mm
Length: 12.7 mm
Core Type: Wirewound
Q Minimum: 23
Shielding: Shielded
Tolerance: 20 %
Inductance: 27 uH
Application: Power
Termination: Standard
Unit Weight: 4.250 g
Core Material: Ferrite
Mounting Style: PCB Mount
Test Frequency: 2.52 MHz
Termination Style: SMD/SMT
Maximum DC Current: 3 A
Saturation Current: 4.3 A
Maximum DC Resistance: 48 mOhms
Self Resonant Frequency: 6.5 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
