Shaping time constant: 4 shaping time constant 0,5...24 us (by request))
Coarse gain: 5,10,20,40,80,160,320,640 (by request)
Fine gain: 1 ... 2
Input signal polarity: +/-
TRP preamplifier support: Yes
Integral nonlinearity: +/- 0,025%
Differential nonlinearity: <1%
Gain temperature coefficient: <50 ppm/0 C
MCA, chn: 16k
Input count rate: up to 200000cps
Power preamp: +/- 12В 60mA; +/- 24В 40mA
HV out: +/-5000 V or +/-2000 V /0.5mA
Power supply: +9... 18 V; 1 А
Consumed power: 12 W
Indication: TFT color touchscreen 3.2"
Communication interface: USB; Ethernet; RS-232 or I/O control by request
