Energy range, keV:
- for gamma radiation: 40-3000
- for beta radiation: 65-4000
- for alpha radiation: 1500-10000
Relative energy resolution on the line 661,7 keV, measuring with radionuclide source Cs-137, %: From 3 to 12 depending on detector type
Maximum throughput, cps: > 5∙104
Integral nonlinearity in the gamma energy range from 40 to 3000 keV, %: 1
Integral nonlinearity in the beta energy range from 65 to 4000 keV, %: 2
Instability of spectrometer indications (energy conversion characteristic) for 24 hours of a continuous operation, %: ±1
Operation conditions:: from +10 to +40
- ambient air temperature, 0С:
- relative air humidity, %: up to 80
- atmospheric pressure in the range of, kPa: from 84 to 106,7
- intensity of magnetic fields of the permanent and variable grid frequencies, А/m: up to 40
